EIP012C0250LSDIL – Eaglerise Constant Current LED Driver 12W – 250mA Fashion

Leading edge & Trailing Edge Dimmable
Constant Current Design
Protections: Short circuit Over Voltage Overload Over Temperature
Other features:

Power Factor >0.9
Class II
3 years warranty
More Information

Manufacturer
Eaglerise

Output Wattage (W)
12

Output Current
250mA

Dimmable (Type)
Triac Leading edge & Trailing edge

Output Voltage Range (V)
23~35

DC Output Adjustment
No

EMC Standards
EN55015; EN61000-3-2 Class C; EN61000-3-3, EN61547; EN61000-4-2 – Performance Criteria B; EN61000-4-5 – 1000V; Performance Criteria C

Input Voltage
220-240VAC

Safety Standards
EN61347-1, EN61347-2-13

Output Voltage Options
Single

Working Temperature
-10~+50°C

PDF Datasheet
EIP012.pdf
