ELED-10-12D – ECOPAC LED DRIVER ELED-10-12D SERIES 10W 12V obsolete no longer available For Cheap

Built-in active PFC function
Dali Dimmable
Protections: Short circuit Over Current Over Loading
Other features:

IP20 Design for Indoor Installations
Dimming function : Built-in Dali interface push dimming
Suitable for intelligent LED lighting
Suitable for dry locations
3 years warranty
More Information

Manufacturer
Ecopac Power

Output Wattage (W)
7

Output Voltage
12

Dimmable (Type)
Choose Option

Dimensions
80x 36x 23

EMC Standards
Compliance to EN55015, EN61000-3-2-3 (>50% load) Compliance to EN61000-4-2,3,4,5,6,11(surge 4KV)

Input Voltage
100-265VAC

Safety Standards
EN61347-1, EN61347-2-13

Output Voltage Options
Single

Working Temperature
-40~+60°C

PDF Datasheet
ELED-10-D UP.pdf
