Product on sale

ELG-200-12A-3Y – Mean Well ELG-200-12A LED Driver 100W 12V – Potentiometer Online Sale

$38.76

25 people are viewing this right now
15 products sold in last 4 hours
Selling fast! Over 13 people have this in their carts
  • Check Mark Estimated Delivery : Up to 4 business days
  • Check Mark Free Shipping & Returns : On all orders over $200
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout

Constant current mode output Typical lifetime>50000 hours
Protections: Short circuit Over Voltage Over temperature
Other features: Built-in active PFC function No load power consumption <0.5W IP67 IP65 rated design for indoor or outdoor installations Metal housing design Various Dimming options. 5 years warranty

More Information:
Manufacturer Mean Well
Output Wattage (W) 200
Output Voltage 12V Dimmable (Type) Potentiometer DC Output Adjustment 11.2-12.8V(A type only)
Dimensions 244x 71x 37.5
EMC Standards Compliance to EN55015, EN61000-3-2 Class C (>50% load) ; EN61000-3-3,GB17625.1, GB17743 Compliance to EN61000-4-2,3,4,5,6,8,11 ; EN61547, light industry level (surge immunity Line-Easrt 6KV, Line-Line 4KV)
Input Voltage 100-305VAC 142-431VDC
Safety Standards UL8750 (type”HL”); CSA C22.2 No. 250 13-12; ENEC EN61347-1, EN61347-2-13 independent, EN62384; GB19510.14, GB19510.1;
IP65 or IP67 approved
Output Voltage Options
Single Working Temperature -40~+90°C
