ELG-200-C-S – Mean Well ELG-200 Series LED Driver 198.8-201.6W 700-2100mA Fashion

$32.37

24 people are viewing this right now
20 products sold in last 13 hours
Selling fast! Over 13 people have this in their carts
  • Check Mark Estimated Delivery : Up to 4 business days
  • Check Mark Free Shipping & Returns : On all orders over $200
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout

Constant current mode outputMetal housing design with functional groundProtections: Short circuit Over Voltage Over temperatureOther features:Built-in active PFC functionNo load standby power consumption <0.5WIP67 IP65 rated design for indoor or outdoor installationsFunction Options: output adjustable via potentiometer: 3 in 1 dimming (dim-to-off); Smart timer dimming; DALITypical lifetime>50000 hours5 years warranty
More Information

Manufacturer

Mean Well

Output Wattage (W)

200

Dimmable (Type)

3 in 1 Dimming

Dimensions

244x 71x 37.5

EMC Standards

Compliance to EN55015, EN61000-3-2 Class C (>50% load) ; EN61000-3-3; GB17625.1, GB17743 Compliance to EN61000-4-2,3,4,5,6,8,11 ; EN61547, light industry level (surge immunity:Line-Earth 6KV, Line-Line 4KV)

Input Voltage

100-305VAC 142-431VDC

Safety Standards

UL8750 (type”HL”); CSA C22.2 No. 250 13-12; ENEC EN61347-1, EN61347-2-13 independent, EN62384; GB19510.14, GB19510.1 ; IP65 or IP67 approved

Output Voltage Options

Single

Working Temperature

Tcase= -40~+85°C (Refer to OUTPUT LOAD vs TEMPERATURE )

PDF Datasheet

ELG-200-C-spec.pdf
