ELG-200-C1750 – Mean Well LED Driver ELG-200-C1750 199.5W 1750mA on Sale

Constant current mode outputMetal housing design with functional groundProtections: Short circuit Over Voltage Over temperatureOther features:Built-in active PFC functionNo load standby power consumption <0.5WIP67 IP65 rated design for indoor or outdoor installationsFunction Options: output adjustable via potentiometer: 3 in 1 dimming (dim-to-off); Smart timer dimming; DALITypical lifetime>50000 hours5 years warranty
More Information

Manufacturer
Mean Well

Output Wattage (W)
200

Output Current
1750mA

Dimmable (Type)
3 in 1 Dimming

Output Voltage Range (V)
57~114

DC Output Adjustment
875-1750mA (A type only)

Dimensions
244x 71x 37.5

EMC Standards
Compliance to EN55015, EN61000-3-2 Class C (>50% load) ; EN61000-3-3; GB17625.1, GB17743 Compliance to EN61000-4-2,3,4,5,6,8,11 ; EN61547, light industry level (surge immunity:Line-Earth 6KV, Line-Line 4KV)

Input Voltage
100-305VAC 142-431VDC

Safety Standards
UL8750 (type”HL”); CSA C22.2 No. 250 13-12; ENEC EN61347-1, EN61347-2-13 independent, EN62384; GB19510.14, GB19510.1 ; IP65 or IP67 approved

Output Voltage Options
Single

Working Temperature
Tcase= -40~+85°C (Refer to OUTPUT LOAD vs TEMPERATURE )

PDF Datasheet
elg-100.pdf
