ELG-240-42 – Mean Well LED Driver ELG-240-42 239.82W 42V Online Sale

Constant current mode output
Metal housing design
Protections: Short circuit Over Voltage Over temperature
Other features:

Built-in active PFC function
No load power consumption <0.5W
IP67 IP65 rated design for indoor or outdoor installations
Typical lifetime>50000 hours
5 years warranty
More Information

Manufacturer
Mean Well

Output Wattage (W)
240

Output Voltage
42V

Dimmable (Type)
3 in 1 Dimming

DC Output Adjustment
21-42V (A type only)

Dimensions
244x 71x 37.5

EMC Standards
Compliance to EN55015, EN61000-3-2 Class C (>50% load) ; EN61000-3-3,GB17625.1, GB17743 Compliance to EN61000-4-2,3,4,5,6,8,11 ; EN61547, light industry level (surge immunity Line-Easrt 6KV, Line-Line 4KV)

Input Voltage
100-305VAC 142-431VDC

Safety Standards
UL8750 (type”HL”); CSA C22.2 No. 250 13-12; ENEC EN61347-1, EN61347-2-13 independent, EN62384; GB19510.14, GB19510.1; IP65 or IP67 approved

Output Voltage Options
Single

Working Temperature
Tcase= -40~+90°C

PDF Datasheet
elg-100.pdf
