HLG-120H-54B – Mean Well LED Driver HLG-120H-54B 120W 54V Online Hot Sale
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
Built-in active PFC function, PF>0.9 for 60% of load or higherIP67 design for indoor or outdoor installationsProtections: Short circuit Over current Over voltage Over temperatureOther features:Universal AC input (up to 305VAC) Full rangeHigh efficiency up to 94% Output current adjustable through output cable or internal potentiometerCooling by free air convectionSuitable for dry, damp and wet locationSuitable for LED lighting and street lighting applicationsMeet 4KV surge immunity level (IEC61000-4-5)Multiple models for choice:Built-in 3 in 1 dimming function (1~10VDC, PWM signal, or resistance)5 years warranty
More Information
Manufacturer
Mean Well
Output Wattage (W)
120
Output Voltage
54V
Dimmable (Type)
1-10VDC, PWM signal, resistance
DC Output Adjustment
-0
Dimensions
220 x 68 x 38.8
EMC Standards
EN55015, EN55022, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, EN55024
Input Voltage
90~305VAC, 127~431VDC
Safety Standards
TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13 approved
Output Voltage Options
Single
Working Temperature
-40~+70°C
PDF Datasheet
HLG-120-spec.pdf
