HLG-120H-CBS – Mean Well HLG-120H-CB Series Dimmable LED Driver 150W – 155W 230mA – 1050mA Online Hot Sale
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
Constant current designThree in one dimming function (1~10Vdc or PWM signal or resistance)Protections: Short circuit Over voltage Over temperatureUniversal AC input Full range (up to 305VAC)Built-in active PFC functionHigh efficiency up to 94%Cooling by free air convectionOutput current adjustable through output cableIP67 design for indoor or outdoor installationsSuitable for dry damp wet locations5 years warranty
More Information
Manufacturer
Mean Well
Output Wattage (W)
120
Output Current
Choose Option
Dimmable (Type)
1-10VDC, PWM signal, resistance
Dimensions
220x 68x 38.8 (LxWxH) Mm
EMC Standards
Compliance to EN55015, EN61000-3-2 Class C (?50% load) ; EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, heavy industry level (surge L,N-FG: 4KV), criteria A
Input Voltage
90 ~ 305VAC, 127~431VDC
Safety Standards
UL8750, CSA C22.2 No. 250.0-08, EN61347-1, EN61347-2-13, EN62384 independent, IP65 approved
Output Voltage Options
Single
Working Temperature
-40~+70°C
PDF Datasheet
HLG-120H-C-spec.pdf
