HLG-60H-CS – Mean Well HLG-60H-C Series LED Driver 70W 350mA – 700mA on Sale

Constant current designThree in one dimming function (1~10Vdc or 10V PWM signal or resistance)Protections: Short circuit Over voltage Over temperatureUniversal AC input Full range (up to 305VAC)Built-in active PFC functionCooling by free air convectionOutput current adjustable through output cableIP67 design for indoor or outdoor installationsSuitable for dry damp wet locationsHigh efficiency up to 91%5 years warranty
More Information

Manufacturer

Mean Well

Output Wattage (W)

70

Output Current

Choose Option

Dimmable (Type)

1-10VDC, PWM signal, resistance

Output Voltage Range (V)

110

Dimensions

171x 61.5x 36.8

EMC Standards

Compliance to EN55015, EN61000-3-2 Class C (¡Ù60% load) ; EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, heavy industry level (surge L,N-FG: 4KV), criteria A

Input Voltage

90~305VAC, 127VDC~431VDC

Safety Standards

UL8750, CSA C22.2 No. 250.0-08, EN61347-1, EN61347-2-13 independent, IP67 approved

Output Voltage Options

Single

Working Temperature

-40~+50°C (refer to output derating curve)

PDF Datasheet

HLG-60H-C-spec.pdf
