HVG-100-42A – Mean Well LED Driver HVG-100-42A 100W 42V Fashion

Output voltage and C.C level can be adjusted through internal potentiometerWide input range: 180~480VACProtections: Short circuit Over voltage Over temperatureOther features:High efficiency up to 92%Built-in active PFCCooling by free air convectionC.V. + C.C. mode designOutput current adjustable through output cable or internal potentiometerSuitable for dry, damp and wet locationsSuitable for LED lighting and street lighting applicationsIP65 design5 years warranty
More Information

Manufacturer
Mean Well

Output Wattage (W)
100

Output Voltage
42V

DC Output Adjustment
+ -10% rated output voltage

EMC Standards
Design refer to EN55015, FCC part 15 class B, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547

Input Voltage
180~480VAC, 254~679VDC

Safety Standards
Design refer to UL8750, TUV EN61347-1, EN61347-2-13

Output Voltage Options
Single

Working Temperature
-40 ~ +70°C(Refer to Derating Curve )

PDF Datasheet
HVG-100-spec_9.pdf
