HVGC-65-500A – Mean Well LED Driver HVGC-65-500A 65W 500mA Cheap
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
Constant current designWide input range 180~528VACOCP point adjustable through internal potentiometerProtections: Short circuit Over current Over voltage Over temperatureOther features:Built-in active PFC functionHigh efficiency up to 90.5%Cooling by free air convectionIP65 design for indoor or outdoor installationsSuitable for LED lighting and street lighting applicationsCompliance to worldwide safety regulations for lightingSuitable for dry damp wet locations5 year warranty
More Information
Manufacturer
Mean Well
Output Wattage (W)
65
Output Current
500mA
Dimmable (Type)
1-10VDC, PWM signal, resistance
Output Voltage Range (V)
13~130
Dimensions
189x 61.5x 36.8
EMC Standards
Compliance to EN55015, EN61000-3-2 Class C (?60% load) ; EN61000-3-3, FCC part 15 class B, EN61000-4-2,3,4,5,6,8,11, EN61547, light industry level (surge 4KV), criteria A
Input Voltage
180~528VAC, 254~747VDC
Safety Standards
UL8750, CSA C22.2 No. 250.0-13, ENEC EN61347-1, EN61347-2-13, EN62384, independent, IP65 approved
Output Voltage Options
Single
Working Temperature
-30~+60°C (Refer to Derating Curve )
PDF Datasheet
HVGC-65-spec.pdf
